LUBE气动活塞泵,润滑泵PM型,PM-5S,PM-5S-100V,PM-8S-L
LUBE Pneumatic piston pump,
PM,PM-5S,PM-5S-100V,PM-8S,102660,102754,102836

泵比例1：5（气压.5MPa）,吐出量8mℓ/CY（6mℓ、7mℓ〜订货生产品） 使用粘度喷涂方法：油雾 10〜100mm2/s,油气 10〜1800mm2/s 液体烟雾,空气压力和空气消费量的特性,0.4MPa—0.27Nℓ/脉冲,0.5MPa—0.3Nℓ/脉冲 阀门总吐出量经5cc,涂抹量（使用0.5ml阀门时可以达到10处） 油箱容量1.8ℓ树脂油箱（标准,3ℓ树脂油箱、3ℓ、4ℓ、8ℓ板金油箱（可选） 可选规格 　三方向電磁阀电压：AC100V、AC200V、DC24V 　油位开关A接点（NO）下限ON 　接点容量AC、DC200V30W、或备阻力负荷,0.5A都是小的　 重量1.8ℓ：1.2kg、8ℓ：11.0kg

Pump ratio 1:5 (under air pressure of 0.5MPa) Discharge，volume，8mℓ/shot (6mℓ, 7mℓ: available by special order) Working，viscosity，Spray method: Oil shot 10-100cSt Oil/air 10-1800cSt，Air pressure vs. air consumption 0.4MPa - 0.27Nl/shot; 0.5MPa - 0.3Nl/shot，Total valve discharge: Approx. 5mℓ System capacity When using 0.5mℓ valve, up to 10 points. Reservoir capacity，1.8ℓ, 3ℓ resin reservoir (standard) 3ℓ resin reservoir, 3ℓ, 4ℓ, 81 metal reservoir (optional) Options,3-way solenoid,valve,Voltage: AC100V, AC200V,DC24V Oil level swith (NO) ON at low level Contact capacity AC, DC200V 30W or resistance,load 0.5A, whichever smaller,Weight 1.8ℓ reservoir: 1.2 kg, 8ℓ reservoir: 11.0kg

由三通电磁阀的开关引起活塞动作的气动泵。 正确使用方法 1, PM 型油泵是由气压引起活塞往返活动的气动泵，所以在空气的切换上必须使用三通切换阀。 2, PM 型油泵设定的是进气压为0.1MPa 时吐出压力为0.5MPa（油泵比例1 ：5）。但是定量阀的动作压力在1.2MPa 以上，所以进气压必须保证设定在0.45 ～ 0.7MPa，还有喷嘴飞出油（液）过多时也不要调整进气压在0.45MPa 以下。 3,使用油（液）的粘度范围是10mm2/s 〜100mm2/s（使用時粘度）。粘度过高情况下短周期间歇时间内也有不能反复出油的情况。 4,PM 型油泵因使用铝材（油泵本身），乙酸树脂（标准油箱）、NBR 橡胶材料（O 型圈），所以使用特殊油（液）的情况请咨询我司。

Pneumatically actuated piston pump for use with positive displacement injectors. Directions for use 1. Install a timer on a machine to be lubricated, and make the operation and pause cycle settings of the three-way solenoid valve drive the pump. 2. Due to the minimum metering valve operating pressure (1.6MPa), adjust the air supply pressure in the range from 0.45 MPa to 0.7 MPa. 3. Use industrial lubricating oil in the range from 10 to 100 mm2/s of ISO viscosity. If the viscosity is too high, oil can not be pumped during short interval operation. 4. Pump contains components manufactured from aluminium (pump body), acetate resin (reservoir) and NBR (o-ring). Contact us if special fluids must be used.

润滑系统、泵维修-更换-调试，Repair-Replace-Adjust

LUBE气动活塞泵,PM型,PM-5S,PM-5S-100V,PM-8S
LUBE Pneumatic piston pump,PM,PM-5S,PM-5S-100V,PM-8S
